    Intelligent Overhead Lifting Load Limiter Mini DIN Electronic Load Control Monitor

    SUMMIT OMS-160 mini DIN rail intelligent electronic load control monitor for crane hoist overload protection


    We SUMMIT has been providing versatile load-limitation systems for all types of cranes and especially overhead cranes. In particular, we have supplied them to the very important players in the lifting and material handling industry as well as in steel industry. That is why we can claim that we have a solid experience and are highly dependable as regards load-limiting devices for cranes which enables us to equip the most complex of systems.

    Description:
    The lifting load limiter OMS-160 is designed for the crane and electric hoist overload lifting protection, or other lfiting equipment such as overhead travelling cranes,hoists, elevators, etc.
    It can be connected on any weight detecting sited in: fixed spur, turn pulley, carrier, cable, etc. Optionally it has an output for weight booster (on pannel of push buttons),easily calibrate the system


    Feature:

    1. Easy mounting

    2. Wide range voltage input, more stable and flexible

    4. 1 entry of weighing load cells

    5. Compatible with all load weighing sensors manufactured by ANT,SUMMIT

    6. With load cells, it constitutes the complete overload limiter

    Control Unit model: OMS-160
    Operation Voltage:AC/DC18-48VDisplay mode:Weight/percentage
    Nominal power:≤4WKey number:4
    Entry qty of load cells1 pcsMeasuring precision:0.1%
    Relay Number:1(overload,1NO/1NC)Operation temperature:-45-+85degree
    Contact Load:5A 250VAC/5A 30VDCSensor operation voltage:Max DC15V
    Display Type:4 digits 0.36 inch LED displayConnection terminals type for load cellCompatible with 4-core bank wire

    Crane Load limit switch OMS-160 Size and wiring diagram:



    A comprehensive kit for crane/hoist overload protection that includes everything needed to install or retrofit on bridge cranes is now available from ANT Lifting Load Weighing Systems.
